The Peak Scientific 500 cc Precision Hydrogen Trace Hydrogen Generator is capable of delivering nitrogen at over 99.9995% purity up to 500 cc/min, suitable for flame gas and carrier gas at trace detection limits . The system offers a safe, reliable and convenient solution, by providing with the highest purity of hydrogen Proton Exchange Membrane to create the hydrogen gas from deionized water, as well as Pressure Swing Absorption and molecular sieve technology to remove moisture content down to trace levels.
The 500cc generators compact and modular design means it can be stacked in multiple variations depending on your labs requirements.
Features of Peak Scientific 500 cc Precision Hydrogen Trace Generator:
- Produce gas on demand up to 500 cc/min at 99.9999% purity
- Internal leak detection with automatic shutdown
- Short and easy start-up/shutdown procedures
- Touchscreen Display
- PEM technology
- Regenerative PSA dryers to ensure highest level of purity
- Automatic loading pump
- Maximum Flow Rate: 500 cc/min
- Maximum Air Pressure: 100 psig
- Simple maintenance – only need to replace de-ionizer cartridge
- Compact design
- Silent operation
- 50/60 Hz
